Description Module:

200mm x 200mm Approx.(8”x8”) Double sided Treated PCB outdoor use.

No. LED’s x Pixel:

Three Superbright Diodes (1 Red, 1 Green & 1 Blue)

Pixel Diameter:

Center  to center spacing: 25mm or 1”.

Viewing angle:

120° / 45°

Controller CPU:

Static bias driver  (direct drive) for more efficient power distribution.

Brightness (NIT):

≥ 6500 cd/m² (minimal).

Power consumption:

0.156 watts per pixel maximum high power efficiency.

Estimated lifetime:

LED manufacturer estimates diode life expectancy at 100,000 hours at 30° C
Sunitron Inc. will warranty diodes for our standard warranty policy period 1year.

Construction:

Waterproof Steel cabinet black plastic coated with 12.7 mm louvers front face.

Cooling System:

Internal Automatic on /off  by force air  (fans).

Display matrix:

8 x 8 per modules of  3 LED’s per pixel Modules are designed to be “snapped” in and out for quick service.

Features:

Time, Date, Temperature, Text Overlay, Sequencing, Scheduling Preview, Remote Control.

Communication:
PC to Sign

Via hardwire (RS232 or RS422) up to 4000 ft.
Modems requires telephone line on site
Wire-less communication.
Operable in TCP/IC for Netware Connectivity

Automatic Dimmer:

Automatic 16 level Light Dimmer (Multi-stage light “Power Saver” sensor and life to display). 128 Level Programmable Light sensor via software

Standard Warranty:

3-years service depot warranty on all parts and labour, including on line direct support toll free # 1-877-630-8811.

Technical Support:

10 year  technical support for software upgrading when available .

Operation Software:

Windows base software (Size, Position, Brightness Control)

Power requirement:

110/120Vac service, internal switch powers supply 13 Vdc.
With automatic circuit for over voltage protection shot-/off.

Electrical cable:

To be determinate by electrical contractor according to CSA standard.
